Siddhigiri Tubes is a distinguished name in the metal tubing industry, known for delivering uncompromising quality and precision. As a leading supplier, we take pride in offering top-grade 4130 Aircraft Tubing, catering to aerospace manufacturers and professionals worldwide.
The 4130 Aircraft Tubing is a specialized alloy steel, celebrated for its exceptional strength-to-weight ratio and superb weldability. Manufactured from premium raw materials, our tubing is engineered to meet the stringent demands of the aerospace industry. Recognized for its outstanding corrosion resistance, fatigue strength, and precise engineering, this tubing is the material of choice for critical aircraft components.
High Strength-to-Weight Ratio: 4130 Aircraft Tubing is renowned for its impressive strength without adding unnecessary weight to the aircraft structure.
Weldability: These tubes are easily weldable, allowing for precise fabrication and customization to meet specific aerospace design requirements.
Compliance and Certification: All our products, including 4130 Aircraft Tubing, meet international standards and undergo rigorous quality control processes. We provide material certificates upon request, demonstrating compliance with industry specifications.
| AISI 4130 CHROMOLY TUBING SIZE IN STOCK |
|---|
| OD X THICK |
| 1/4” OD x 0.035” ( 6.35 MM OD X 0.9 MM ) |
| 1/4” OD x 0.04” ( 6.35 MM OD X 1 MM ) |
| 1/4” OD x 0.05” ( 6.35 MM OD X 1.25 MM ) |
| 1/4” OD x 0.06” ( 6.35 MM OD X 1.5 MM ) |
| 1/4” OD x 0.08” ( 6.35 MM OD X 2 MM ) |
| 8 MM OD X 0.9 MM |
| 8 MM OD X 1 MM |
| 8 MM OD X 1.25 MM |
| 8 MM OD X 1.5 MM |
| 8 MM OD X 2 MM |
| 3/8” OD x 0.035” ( 9.5 MM OD X 0.9 MM ) |
| 3/8” OD x 0.04” ( 9.5 MM OD X 1 MM ) |
| 3/8” OD x 0.05” ( 9.5 MM OD X 1.25 MM ) |
| 3/8” OD x 0.06” ( 9.5 MM OD X 1.5 MM ) |
| 3/8” OD x 0.08” ( 9.5 MM OD X 2 MM ) |
| 10 MM OD X 0.9 MM |
| 10 MM OD X 1 MM |
| 10 MM OD X 1.25 MM |
| 10 MM OD X 1.5 MM |
| 10 MM OD X 2 MM |
| 1/2” OD x 0.035” ( 12.7 MM OD X 0.9 MM ) |
| 1/2” OD x 0.04” ( 12.7 MM OD X 1 MM ) |
| 1/2” OD x 0.05” ( 12.7 MM OD X 1.25 MM ) |
| 1/2” OD x 0.06” ( 12.7 MM OD X 1.5 MM ) |
| 1/2” OD x 0.08” ( 12.7 MM OD X 2 MM ) |
| 5/8” OD x 0.035” ( 15.88 MM OD X 0.9 MM ) |
| 5/8” OD x 0.04” ( 15.88 MM OD X 1 MM ) |
| 5/8” OD x 0.05” ( 15.88 MM OD X 1.25 MM ) |
| 5/8” OD x 0.06” ( 15.88 MM OD X 1.5 MM ) |
| 5/8” OD x 0.08” ( 15.88 MM OD X 2 MM ) |
| 16 MM OD X 0.9 MM |
| 16 MM OD X 1 MM |
| 16 MM OD X 1.25 MM |
| 16 MM OD X 1.5 MM |
| 16 MM OD X 2 MM |
| 18 MM OD X 0.9 MM |
| 18 MM OD X 1 MM |
| 18 MM OD X 1.25 MM |
| 18 MM OD X 1.5 MM |
| 18 MM OD X 2 MM |
| 3/4” OD x 0.035” ( 19.05 MM OD X 0.9 MM ) |
| 3/4” OD x 0.04” ( 19.05 MM OD X 1 MM ) |
| 3/4” OD x 0.05” ( 19.05 MM OD X 1.25 MM ) |
| 3/4” OD x 0.06” ( 19.05 MM OD X 1.5 MM ) |
| 3/4” OD x 0.08” ( 19.05 MM OD X 2 MM ) |
| 7/8” OD x 0.035” ( 22.2 MM OD X 0.9 MM ) |
| 7/8” OD x 0.04” ( 22.2 MM OD X 1 MM ) |
| 7/8” OD x 0.05” ( 22.2 MM OD X 1.25 MM ) |
| 7/8” OD x 0.06” ( 22.2 MM OD X 1.5 MM ) |
| 7/8” OD x 0.08” ( 22.2 MM OD X 2 MM ) |
| 1” OD x 0.035” ( 25.4 MM OD X 0.9 MM ) |
| 1” OD x 0.04” ( 25.4 MM OD X 1 MM ) |
| 1” OD x 0.05” ( 25.4 MM OD X 1.25 MM ) |
| 1” OD x 0.06” ( 25.4 MM OD X 1.5 MM ) |
| 1” OD x 0.08” ( 25.4 MM OD X 2 MM ) |
| 1” OD x 0.095” ( 25.4 MM OD X 2.5 MM ) |
| 1” OD x 0.12” ( 25.4 MM OD X 3 MM ) |
| 1.1” OD x 0.035” ( 28.2 MM OD X 0.9 MM ) |
| 1.1” OD x 0.04” ( 28.2 MM OD X 1 MM ) |
| 1.1” OD x 0.05” ( 28.2 MM OD X 1.25 MM ) |
| 1.1” OD x 0.06” ( 28.2 MM OD X 1.5 MM ) |
| 1.1” OD x 0.08” ( 28.2 MM OD X 2 MM ) |
| 1.1” OD x 0.095” ( 28.2 MM OD X 2.5 MM ) |
| 1.1” OD x 0.12” ( 28.2 MM OD X 3 MM ) |
| 1.15” OD x 0.035” ( 29.2 MM OD X 0.9 MM ) |
| 1.15” OD x 0.04” ( 29.2 MM OD X 1 MM ) |
| 1.15” OD x 0.05” ( 29.2 MM OD X 1.25 MM ) |
| 1.15” OD x 0.06” ( 29.2 MM OD X 1.5 MM ) |
| 1.15” OD x 0.08” ( 29.2 MM OD X 2 MM ) |
| 1.15” OD x 0.095” ( 29.2 MM OD X 2.5 MM ) |
| 1.15” OD x 0.12” ( 29.2 MM OD X 3 MM ) |
| 1.25” OD x 0.035” ( 31.75 MM OD X 0.9 MM ) |
| 1.25” OD x 0.04” ( 31.75 MM OD X 1 MM ) |
| 1.25” OD x 0.05” ( 31.75 MM OD X 1.25 MM ) |
| 1.25” OD x 0.06” ( 31.75 MM OD X 1.5 MM ) |
| 1.25” OD x 0.08” ( 31.75 MM OD X 2 MM ) |
| 1.25” OD x 0.095” ( 31.75 MM OD X 2.5 MM ) |
| 1.25” OD x 0.12” ( 31.75 MM OD X 3 MM ) |
| 1.5” OD x 0.035” ( 38.1 MM OD X 0.9 MM ) |
| 1.5” OD x 0.04” ( 38.1 MM OD X 1 MM ) |
| 1.5” OD x 0.05” ( 38.1 MM OD X 1.25 MM ) |
| 1.5” OD x 0.06” ( 38.1 MM OD X 1.5 MM ) |
| 1.5” OD x 0.08” ( 38.1 MM OD X 2 MM ) |
| 1.5” OD x 0.095” ( 38.1 MM OD X 2.5 MM ) |
| 1.5” OD x 0.12” ( 38.1 MM OD X 3 MM ) |
| 1.75” OD x 0.035” ( 44.5 MM OD X 0.9 MM ) |
| 1.75” OD x 0.04” ( 44.5 MM OD X 1 MM ) |
| 1.75” OD x 0.05” ( 44.5 MM OD X 1.25 MM ) |
| 1.75” OD x 0.06” ( 44.5 MM OD X 1.5 MM ) |
| 1.75” OD x 0.08” ( 44.5 MM OD X 2 MM ) |
| 1.75” OD x 0.095” ( 44.5 MM OD X 2.5 MM ) |
| 1.750” OD x 0.12” ( 44.5 MM OD X 3 MM ) |
| 2” OD x 0.035” ( 50.8 MM OD X 0.9 MM ) |
| 2” OD x 0.04” ( 50.8 MM OD X 1 MM ) |
| 2” OD x 0.05” ( 50.8 MM OD X 1.25 MM ) |
| 2” OD x 0.06” ( 50.8 MM OD X 1.5 MM ) |
| 2” OD x 0.08” ( 50.8 MM OD X 2 MM ) |
| 2” OD x 0.095” ( 50.8 MM OD X 2.5 MM ) |
| 2” OD x 0.12” ( 50.8 MM OD X 3 MM ) |
| OD inches | Ave. Wall inches | Min Yield Strength (PSI) | Min Tensile Strength (PSI) | Theoretical Burst Pressure * (PSI) | Working Pressure (PSI) 25% of Burst | Theoretical Yield Point ** (PSI) | Collapse Pressure *** (PSI) |
|---|---|---|---|---|---|---|---|
| 0.250 | 0.020 | 30,000 | 75,000 | 14,286 | 3,571 | 5,714 | 4,416 |
| 0.250 | 0.028 | 30,000 | 75,000 | 21,649 | 5,412 | 8,660 | 5,967 |
| 0.250 | 0.035 | 30,000 | 75,000 | 29,167 | 7,292 | 11,667 | 7,224 |
| 0.250 | 0.049 | 30,000 | 75,000 | 48,355 | 12,089 | 19,342 | 9,455 |
| 0.250 | 0.065 | 30,000 | 75,000 | 81,250 | 20,313 | 32,500 | 11,544 |
| 0.375 | 0.020 | 30,000 | 75,000 | 8,955 | 2,239 | 3,582 | 3,029 |
| 0.375 | 0.028 | 30,000 | 75,000 | 13,166 | 3,292 | 5,266 | 4,145 |
| 0.375 | 0.035 | 30,000 | 75,000 | 17,213 | 4,303 | 6,885 | 5,077 |
| 0.375 | 0.049 | 30,000 | 75,000 | 26,534 | 6,634 | 10,614 | 6,816 |
| 0.375 | 0.065 | 30,000 | 75,000 | 39,796 | 9,949 | 15,918 | 8,597 |
| 0.500 | 0.020 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,201 |
| 0.500 | 0.028 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.500 | 0.035 | 30,000 | 75,000 | 12,209 | 3,052 | 4,884 | 3,906 |
| 0.500 | 0.049 | 30,000 | 75,000 | 18,284 | 4,571 | 7,313 | 5,201 |
| 0.500 | 0.065 | 30,000 | 75,000 | 26,351 | 6,588 | 10,541 | 6,786 |
| 0.500 | 0.083 | 30,000 | 75,000 | 37,275 | 9,319 | 14,910 | 8,307 |
| 0.625 | 0.020 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
| 0.625 | 0.028 | 30,000 | 75,000 | 7,381 | 1,845 | 2,953 | 2,568 |
| 0.625 | 0.035 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.625 | 0.049 | 30,000 | 75,000 | 13,947 | 3,487 | 5,579 | 4,335 |
| 0.625 | 0.065 | 30,000 | 75,000 | 19,697 | 4,924 | 7,879 | 5,591 |
| 0.625 | 0.083 | 30,000 | 75,000 | 27,124 | 6,781 | 10,850 | 6,910 |
| 0.625 | 0.095 | 30,000 | 75,000 | 32,759 | 8,190 | 13,103 | 7,734 |
| 0.625 | 0.109 | 30,000 | 75,000 | 40,172 | 10,043 | 16,069 | 8,639 |
| 0.750 | 0.028 | 30,000 | 75,000 | 6,052 | 1,513 | 2,421 | 2,156 |
| 0.750 | 0.035 | 30,000 | 75,000 | 7,721 | 1,930 | 3,088 | 2,669 |
| 0.750 | 0.049 | 30,000 | 75,000 | 11,273 | 2,818 | 4,509 | 3,664 |
| 0.750 | 0.065 | 30,000 | 75,000 | 15,726 | 3,931 | 6,290 | 4,749 |
| 0.750 | 0.083 | 30,000 | 75,000 | 21,318 | 5,330 | 8,527 | 5,905 |
| 0.750 | 0.095 | 30,000 | 75,000 | 25,446 | 6,362 | 10,179 | 6,637 |
| 0.750 | 0.109 | 30,000 | 75,000 | 30,733 | 7,683 | 12,293 | 7,453 |
| 0.750 | 0.120 | 30,000 | 75,000 | 35,294 | 8,824 | 14,118 | 8,064 |
| 0.875 | 0.020 | 30,000 | 75,000 | 3,593 | 898 | 1,437 | 1,340 |
| 0.875 | 0.028 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
| 0.875 | 0.035 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,201 |
| 0.875 | 0.049 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.875 | 0.065 | 30,000 | 75,000 | 13,087 | 3,272 | 5,235 | 4,126 |
| 0.875 | 0.083 | 30,000 | 75,000 | 17,560 | 4,390 | 7,024 | 5,152 |
| 0.875 | 0.095 | 30,000 | 75,000 | 20,803 | 5,201 | 8,321 | 5,807 |
| 0.875 | 0.109 | 30,000 | 75,000 | 24,886 | 6,221 | 9,954 | 6,543 |
| 0.875 | 0.120 | 30,000 | 75,000 | 28,346 | 7,087 | 11,339 | 7,100 |
| 1.000 | 0.028 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
| 1.000 | 0.035 | 30,000 | 75,000 | 5,645 | 1,411 | 2,258 | 2,027 |
| 1.000 | 0.049 | 30,000 | 75,000 | 8,149 | 2,037 | 3,259 | 2,796 |
| 1.000 | 0.065 | 30,000 | 75,000 | 11,207 | 2,802 | 4,483 | 3,647 |
| 1.000 | 0.083 | 30,000 | 75,000 | 14,928 | 3,732 | 5,971 | 4,567 |
| 1.000 | 0.095 | 30,000 | 75,000 | 17,593 | 4,398 | 7,037 | 5,159 |
| 1.000 | 0.109 | 30,000 | 75,000 | 20,908 | 5,227 | 8,363 | 5,827 |
| 1.000 | 0.120 | 30,000 | 75,000 | 23,684 | 5,921 | 9,474 | 6,336 |
| 1.000 | 0.134 | 30,000 | 75,000 | 27,459 | 6,865 | 10,984 | 6,963 |
| 1.250 | 0.035 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
| 1.250 | 0.049 | 30,000 | 75,000 | 6,380 | 1,595 | 2,552 | 2,260 |
| 1.250 | 0.065 | 30,000 | 75,000 | 8,705 | 2,176 | 3,482 | 2,958 |
| 1.250 | 0.083 | 30,000 | 75,000 | 11,485 | 2,871 | 4,594 | 3,719 |
| 1.250 | 0.095 | 30,000 | 75,000 | 13,443 | 3,361 | 5,377 | 4,213 |
| 1.250 | 0.109 | 30,000 | 75,000 | 15,843 | 3,961 | 6,337 | 4,776 |
| 1.250 | 0.120 | 30,000 | 75,000 | 17,822 | 4,455 | 7,129 | 5,207 |
| 1.250 | 0.134 | 30,000 | 75,000 | 20,468 | 5,117 | 8,187 | 5,742 |
| 1.500 | 0.035 | 30,000 | 75,000 | 3,671 | 918 | 1,469 | 1,367 |
| 1.500 | 0.049 | 30,000 | 75,000 | 5,243 | 1,311 | 2,097 | 1,896 |
| 1.500 | 0.065 | 30,000 | 75,000 | 7,117 | 1,779 | 2,847 | 2,487 |
| 1.500 | 0.083 | 30,000 | 75,000 | 9,333 | 2,333 | 3,733 | 3,136 |
| 1.500 | 0.095 | 30,000 | 75,000 | 10,878 | 2,719 | 4,351 | 3,559 |
| 1.500 | 0.109 | 30,000 | 75,000 | 12,754 | 3,188 | 5,101 | 4,043 |
| 1.500 | 0.120 | 30,000 | 75,000 | 14,286 | 3,571 | 5,714 | 4,416 |
| 1.500 | 0.134 | 30,000 | 75,000 | 16,315 | 4,079 | 6,526 | 4,881 |
| 1.500 | 0.148 | 30,000 | 75,000 | 18,439 | 4,610 | 7,375 | 5,336 |
| 1.750 | 0.035 | 30,000 | 75,000 | 3,125 | 781 | 1,250 | 1,176 |
| 1.750 | 0.049 | 30,000 | 75,000 | 3,864 | 966 | 1,546 | 1,434 |
| 1.750 | 0.065 | 30,000 | 75,000 | 6,019 | 1,505 | 2,407 | 2,146 |
| 1.750 | 0.083 | 30,000 | 75,000 | 7,860 | 1,965 | 3,144 | 2,711 |
| 1.750 | 0.095 | 30,000 | 75,000 | 9,135 | 2,284 | 3,654 | 3,080 |
| 1.750 | 0.109 | 30,000 | 75,000 | 10,672 | 2,668 | 4,213 | 3,504 |
| 1.750 | 0.120 | 30,000 | 75,000 | 11,921 | 2,980 | 4,768 | 3,832 |
| 1.750 | 0.134 | 30,000 | 75,000 | 13,563 | 3,391 | 5,425 | 4,242 |
| 1.750 | 0.148 | 30,000 | 75,000 | 15,268 | 3,817 | 6,107 | 4,645 |
| 1.750 | 0.165 | 30,000 | 75,000 | 17,430 | 4,357 | 6,972 | 5,124 |
| 2.000 | 0.035 | 30,000 | 75,000 | 2,720 | 680 | 1,088 | 1,032 |
| 2.000 | 0.049 | 30,000 | 75,000 | 3,864 | 966 | 1,546 | 1,434 |
| 2.000 | 0.065 | 30,000 | 75,000 | 5,214 | 1,303 | 2,086 | 1,887 |
| 2.000 | 0.083 | 30,000 | 75,000 | 6,788 | 1,697 | 2,715 | 2,387 |
| 2.000 | 0.095 | 30,000 | 75,000 | 7,873 | 1,968 | 3,149 | 2,715 |
| 2.000 | 0.109 | 30,000 | 75,000 | 9,175 | 2,294 | 3,670 | 3,092 |
| 2.000 | 0.120 | 30,000 | 75,000 | 10,227 | 2,557 | 4,091 | 3,384 |
| 2.000 | 0.134 | 30,000 | 75,000 | 11,605 | 2,901 | 4,642 | 3,751 |
| 2.000 | 0.148 | 30,000 | 75,000 | 13,028 | 3,257 | 5,211 | 4,111 |
| 2.000 | 0.165 | 30,000 | 75,000 | 14,820 | 3,705 | 5,928 | 4,542 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength, ultimate | 560 MPa | 81200 psi |
| Tensile strength, yield | 460 MPa | 66700 psi |
| Modulus of elasticity | 190-210 GPa | 27557-30458 ksi |
| Bulk modulus (Typical for steel) | 140 GPa | 20300 ksi |
| Shear modulus (Typical for steel) | 80 GPa | 11600 ksi |
| Poissons ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (in 50 mm) | 21.50% | 21.50% |
| Reduction of area | 59.6 | 59.60% |
| Hardness, Brinell | 217 | 217 |
| Hardness, Knoop (Converted from Brinell hardness) | 240 | 240 |
| Hardness, Rockwell B (Converted from Brinell hardness) | 95 | 95 |
| Hardness, Rockwell C (Converted from Brinell hardness, value below normal HRC range, for comparison purposes only.) | 17 | 17 |
| Hardness, Vickers (Converted from Brinell hardness) | 228 | 228 |
| Machinability (Annealed and cold drawn. Based on 100% machinability for AISI 1212 steel.) | 70 | 70 |
|
NPS [DN] Designator
|
Over
|
Under
|
||
|
in.
|
mm
|
in.
|
mm
|
|
|
1/8 to 1 1/2 [6 to 40], incl.
|
1/64 (0.015)
|
0.40
|
1/64 (0.015)
|
0.40
|
|
Over 1 1/2 to 4 [40 to 100], incl.
|
1/32 (0.031)
|
0.79
|
1/32 (0.031)
|
0.79
|
|
Over 4 to 8 [100 to 200], incl.
|
1/16 (0.062)
|
1.59
|
1/32 (0.031)
|
0.79
|
|
Over 8 to 12 [200 to 300], incl.
|
3/32 (0.093)
|
2.38
|
1/32 (0.031)
|
0.79
|
|
Over 12 [300]
|
+/- 1% of the specified outside diameter
|
|||
| Element | Content (%) |
|---|---|
| Iron, Fe | 97.03 – 98.22 |
| Chromium, Cr | 0.80 – 1.10 |
| Manganese, Mn | 0.40 – 0.60 |
| Carbon, C | 0.280 – 0.330 |
| Silicon, Si | 0.15 – 0.30 |
| Molybdenum, Mo | 0.15 – 0.25 |
| Sulfur, S | 0.040 |
| Phosphorous, P | 0.035 |
| Properties | Metric | Imperial |
|---|---|---|
| Density | 7.85 g/cm3 | 0.284 lb/in³ |
| Melting point | 1432°C | 2610°F |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength, ultimate | 560 MPa | 81200 psi |
| Tensile strength, yield | 460 MPa | 66700 psi |
| Modulus of elasticity | 190-210 GPa | 27557-30458 ksi |
| Bulk modulus (Typical for steel) | 140 GPa | 20300 ksi |
| Shear modulus (Typical for steel) | 80 GPa | 11600 ksi |
| Poissons ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (in 50 mm) | 21.50% | 21.50% |
| Reduction of area | 59.6 | 59.60% |
| Hardness, Brinell | 217 | 217 |
| Hardness, Knoop (Converted from Brinell hardness) | 240 | 240 |
| Hardness, Rockwell B (Converted from Brinell hardness) | 95 | 95 |
| Hardness, Rockwell C (Converted from Brinell hardness, value below normal HRC range, for comparison purposes only.) | 17 | 17 |
| Hardness, Vickers (Converted from Brinell hardness) | 228 | 228 |
| Machinability (Annealed and cold drawn. Based on 100% machinability for AISI 1212 steel.) | 70 | 70 |
| O.D.(mm) x Thickness(mm) | O.D(mm) x Thickness(mm) | O.D(mm) x Thickness(mm) |
|---|---|---|
| 38.1 x 3.2 | 57.0 x 4.9 | 76.2 x 4.0 |
| 38.1 x 4.0 | 57.0 x 6.3 | 76.2 x 5.0 |
| 38.1 x 6.3 | 57.0 x 7.9 | 76.2 x 6.3 |
| 42.4 x 3.2 | 60.3 x 3.2 | 82.5 x 4.5 |
| 42.4 x 4.0 | 60.3 x 3.6 | 88.9 x 3.2 |
| 44.5 x 3.2 | 60.3 x 5.0 | 88.9 x 3.6 |
| 44.5 x 6.3 | 63.5 x 3.2 | 88.9 x 4.0 |
| 48.3 x 3.2 | 63.5 x 3.6 | 101.6 x 3.6 |
| 48.3 x 3.6 | 63.5 x 4.0 | 101.6 x 4.5 |
| 50.8 x 4.5 | 63.5 x 6.3 | 101.6 x 6.3 |
| 51.0 x 3.2 | 63.5 x 7.9 | 114.3 x 3.6 |
| 51.0 x 3.6 | 70.0 x 3.2 | 114.3 x 5.0 |
| 51.0 x 6.3 | 70.0 x 3.6 | 139.7 x 4.0 |
| 57.0 x 3.2 | 70.0 x 6.3 | 139.7 x 5.0 |
| 57.0 x 3.6 | 76.2 x 3.6 | 139.7 x 6.3 |
| NB | Size | OD | 40S | 5S | 10S | S10 | S20 | S40 | S60 | XS/80S | S80 | S100 | S120 | S140 | S160 | XXS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | ||
| 1/8” | 10.29 | 1.2 | 1.73 | 2.41 | ||||||||||||
| 1/4” | 13.72 | 1.7 | 2.24 | 3.02 | ||||||||||||
| 3/8” | 17.15 | 1.7 | 2.31 | 3.2 | ||||||||||||
| 15 | 1/2” | 21.34 | 2.8 | 1.7 | 2.1 | 2.77 | 3.73 | 3.73 | 4.78 | 7.47 | ||||||
| 20 | 3/4” | 26.67 | 2.9 | 1.7 | 2.1 | 2.87 | 3.91 | 3.91 | 5.56 | 7.82 | ||||||
| 25 | 1” | 33.4 | 3.4 | 1.7 | 2.8 | 3.38 | 4.55 | 4.55 | 6.35 | 9.09 | ||||||
| 32 | 1 1/4” | 42.16 | 3.6 | 1.7 | 2.8 | 3.56 | 4.85 | 4.85 | 6.35 | 9.7 | ||||||
| 40 | 1 1/2” | 48.26 | 3.7 | 1.7 | 2.8 | 3.68 | 5.08 | 5.08 | 7.14 | 10.2 | ||||||
| 50 | 2” | 60.33 | 3.9 | 1.7 | 2.8 | 3.91 | 5.54 | 5.54 | 9.74 | 11.1 | ||||||
| 65 | 2 1/2” | 73.03 | 5.2 | 2.1 | 3.1 | 5.16 | 7.01 | 7.01 | 9.53 | 14 | ||||||
| 80 | 3” | 88.9 | 5.5 | 2.1 | 3.1 | 5.49 | 7.62 | 7.62 | 11.1 | 15.2 | ||||||
| 90 | 3 1/2” | 101.6 | 5.7 | 2.1 | 3.1 | 5.74 | 8.08 | 8.08 | ||||||||
| 100 | 4” | 114.3 | 6 | 2.1 | 3.1 | 6.02 | 8.56 | 8.56 | 11.1 | 13.5 | 17.1 | |||||
| 125 | 5” | 141.3 | 6.6 | 2.8 | 3.4 | 6.55 | 9.53 | 9.53 | 12.7 | 15.9 | 19.1 | |||||
| 150 | 6” | 168.3 | 7.1 | 2.8 | 3.4 | 7.11 | 10.97 | 11 | 14.3 | 18.3 | 22 | |||||
| 200 | 8” | 219.1 | 8.2 | 2.8 | 3.8 | 6.4 | 8.18 | 10.3 | 12.7 | 12.7 | 15.1 | 19.3 | 20.6 | 23 | 22.2 | |
| 250 | 10” | 273.1 | 9.3 | 3.4 | 4.2 | 6.4 | 9.27 | 12.7 | 12.7 | 15.1 | 19.3 | 21.4 | 25.4 | 28.6 | 25.4 | |
| 300 | 12” | 323.9 | 9.5 | 4 | 4.6 | 6.4 | 10.3 | 14.3 | 12.7 | 17.5 | 21.4 | 25.4 | 28.6 | 33.3 | 25.4 | |
| 350 | 14” | 355.6 | 9.5 | 4 | 4.8 | 6.4 | 7.9 | 11.1 | 15.1 | 12.7 | 19.1 | 23.8 | 27.8 | 31.8 | 35.7 | |
| 400 | 16” | 406.4 | 9.5 | 4.2 | 4.8 | 6.4 | 7.9 | 12.7 | 16.7 | 12.7 | 21.4 | 26.2 | 31 | 36.5 | 40.5 | |
| 450 | 18” | 457.2 | 9.5 | 4.2 | 4.8 | 6.4 | 7.9 | 14.3 | 19.1 | 12.7 | 23.8 | 29.4 | 34.9 | 39.7 | 45.2 | |
| 500 | 20” | 508 | 9.5 | 4.8 | 5.5 | 6.4 | 9.5 | 15.1 | 20.6 | 12.7 | 26.2 | 32.5 | 38.1 | 44.5 | 50 | |
| 550 | 22” | 558.8 | 9.5 | 4.8 | 5.5 | 6.4 | 9.5 | 22.2 | 12.7 | 28.6 | 34.9 | 41.3 | 47.6 | 54 | ||
| 600 | 24” | 609.6 | 9.5 | 5.5 | 6.4 | 6.4 | 9.5 | 17.5 | 24.6 | 12.7 | 31 | 38.9 | 46 | 52.4 | 59.5 | |
| 650 | 26” | 660.4 | 9.5 | 7.9 | 13 | 12.7 | ||||||||||
| 700 | 28” | 711.2 | 9.5 | 7.9 | 13 | 12.7 | ||||||||||
| 750 | 30” | 762 | 9.5 | 6.4 | 7.9 | 7.9 | 13 | 12.7 | ||||||||
| 800 | 32” | 812.8 | 9.5 | 7.9 | 13 | 17.5 | 12.7 | |||||||||
| 850 | 34” | 863.6 | 9.5 | 7.9 | 13 | 17.5 | 12.7 | |||||||||
| 900 | 36” | 914.4 | 9.5 | 7.9 | 13 | 19.1 | 12.7 |
| UNS G41300 Aircraft Tubes Supplier |
AISI 4130 Chromoly Aircraft Tube Suppliers
|
| BS 970 Chromium Molybdenum Condenser Tube |
4130 Aircraft Tubing Supplier
|
| ASTM A519 Grade 4130 Aircraft Tubing |
large diameter ASTM A519 Grade 4130 Tubes
|
| AISI 4130 Chromoly Square Tube |
6 Inch AISI 4130 Chromoly Tubes
|
| Schedule 40 AISI 4130 Chromoly Polish Tube |
Schedule 80 SS AISI 4130 Aircraft Tube Per Foot
|
| AISI 4130 Chromoly Aircraft Tube |
AISI 4130 Chromoly Schedule 80 Perforated Tubes
|
| Schedule 10 AISI 4130 Chromoly Aircraft Tubing |
SS AISI 4130 Mechanical Tube Supplier
|
| 6 Inch AISI 4130 Chromoly Rectangular Tube |
AISI 4130 Chromoly U Shaped Tubes
|
| AISI 4130 Chromoly Nuclear Tubes |
6 Inch AISI 4130 Chromoly Aircraft Tubes
|
| ASTM A519 Grade 4130 Square Tubing |
WNR. 1.7218 Electropolished Tubes
|
| EN 25CrMo4 Instrumentation Tube |
1/2″ NB in Thickness SS AISI 4130 Tubes
|
| JIS G4105 High Pressure Tube |
AISI 4130 Chromoly Instrumentation Tubes
|
| Schedule 80 AISI 4130 Chromoly Tubes |
AISI 4130 Chromoly Round Tube
|
| ASTM A519 Grade 4130 Tubing |
Schedule 10 SS AISI 4130 Heat Resistant Tubing
|
| EN 25CrMo4 Bellows Tubes |
ASTM A519 Grade 4130 Exhaust Tube Supplier
|
| AISI 4130 Chromoly Sanitary Tube |
SS DIN 1.7218 Round Tubing
|
| custom Chromium Molybdenum Tubing |
14″ NB in Thickness Schedule ASTM A519 Grade 4130 Tube
|
| SS AISI 4130 Needle Tube |
AISI 4130 Chromoly Oval Tubes Supplier
|
| 2 Inch ASTM A519 Grade 4130 Finned Tube |
JIS G4105 Chromoly Thin Wall Tubing
|
| EN 25CrMo4 Seamless Manufacturer in India |
AISI 4130 Chromoly Pressure Tubing
|
| AISI 4130 Chromoly Tube Schedule 80 |
AISI 4130 Chromoly Oval Tube Supplier
|
| AISI 4130 Chromoly Tubes Supplier |
ASTM A519 Grade 4130 Aircraft Tubing
|
| SS AISI 4130 Tubing Supplier |
4130 Chassis Tube Racing Cars
|
| AISI 4130 Chromoly Hot Finished Seamless Tubing |
AISI 4130 Chromoly Tube Supplier in Mumbai
|
| AISI 4130 Chromoly Pressure Tubing |
AISI 4130 Chromoly Boiler Tube
|
| Marine Grade AISI 4130 Chromoly Tube |
6 Inch ASTM A519 Grade 4130 Exhaust Tubing
|
| AISI 4130 Chromoly Electropolished Tube |
Chromium Molybdenum Seamless Tubing
|
| Stainless Steel U Tube |
5″ NB in Thickness Schedule SS AISI 4130 Tube
|
| ASTM A519 Grade 4130 Seamless Tubes supplier |
Schedule 40 SS AISI 4130 Cold drawn Seamless Tubing
|
| SS AISI 4130 Rectangular Tubes |
AISI 4130 Chromoly Hollow Tube Exporter
|
| ASTM A519 Grade 4130 Radiant Tube |
AISI 4130 Chromoly Precision Tubing Suppliers
|
| High Quality ASTM A519 Grade 4130 Seamless Tube |
16″ NB in Thickness AISI 4130 Chromoly Tube
|
| AISI 4130 Chromoly Aircraft Tubing |
SS AISI 4130 Hollow Tube Supplier
|
| Aircraft Spruce 4130 Tubing Supplier |
Alloy 4130 Stainless Steel Tubes Boiler
|
| Cold Rolled ASTM A519 Grade 4130 Tube Suppliers |
4130 Chromium Molybdenum SCH 40 Welded Tube
|
| UNS G41300 Ornamental Tube |
Alloy 4130 Stainless Steel Capillary Tubes
|
| DIN. 1.7218 Tubing |
AISI 4130 Chromoly Tube Schedule 80 Supplier
|
| AISI 4130 Chromoly Decorative Tube |
EN 25CrMo4 Chromoly Capillary Tube
|
| Schedule 10 ASTM A519 Grade 4130 Hollow Tubes |
AISI 4130 Chromoly Secondary & Surplus Tube
|
| ASTM A519 Grade 4130 Small Diameter Tubes |
AISI 4130 Chromoly Capillary Tube Supplier
|
| 4″ NB in Thickness Schedule SS AISI 4130 Tube Supplier |
UNS G41300 Seamless Tubes
|
| Alloy 4130 SS SCH 80 Tube |
AISI 4130 Chromoly Hollow Tube
|
| AISI 4130 Chromoly Perforated Tube |
WERKSTOFF NR. 1.7218 Condensers Tubes
|
| ASTM A519 Grade 4130 Precision Tubing Suppliers |
18″ NB in Thickness Schedule SS AISI 4130 Tube
|
| AISI 4130 Chromoly Round Tubes suppliers |
Alloy 4130 Stainless Steel Rectangular Tube
|
| 6″ NB in Thickness AISI 4130 Chromoly Tube Supplier |
ASTM A519 Grade 4130 Capillary Tubes
|
| AISI 4130 Chromoly Mechanical Tube |
WERKSTOFF NR. 1.7218 Capillary Tubes
|
| AISI 4130 Chromoly Elliptical Tube |
SS AISI 4130 Round Tubes Supplier & Manufacturer
|
| 4130 Roll Cage Tubing Supplier |
Schedule 40 AISI 4130 Chromoly Tubes Supplier
|
| AISI 4130 Chromoly exhaust Tubes suppliers |
Chromium Molybdenum 4130 Hydraulic Tubes
|
USA,, Mumbai, India, UK, Dubai, Melbourne, Sydney, Adelaide, Brisbane, Queensland, Abu Dhabi, Sharjah, Jebel Ali, Fujairah, Doha, Muscat, Bangkok, Istanbul, Amman, Jerusalem, Tehran, Jeddah, Riyadh, Dammam, Kuala Lumpur, Malacca, Seoul, Cairo, Alexandria, Tokyo, Shanghai, Jakarta, Athens, Rome, Cape Town, Europe, Algeria | American Samoa | Andorra | Angola | Argentina | Aruba | Australia | Austria | Azerbaijan | Bahamas | Bahrain | Bangladesh | Belarus | Belgium | Bermuda | Bhutan | Bolivia | Bosnia | Botswana | Brazil | Brunei | Bulgaria | Cambodia | Cameroon | Canada | Africa | Chile | China | Colombia | Croatia| Cyprus | Czech Republic | Denmark | Djibouti | Ecuador | Egypt | Europe | Estonia |Ethiopia | Fiji | Finland | France | Georgia | Germany | Greece | Hong Kong | Hungary | Iceland | Indonesia | Iran | Ireland | Israel | Italy | Japan | New Jersey | Jordan | Kazakhstan | Kenya | Kuwait | Latvia | Lebanon | Lesotho | Lithuania | Luxembourg | Malaysia | Maldives | Mauritius | Mexico | Morocco| Myanmar | Namibia | Nepal | Netherlands | New Zealand | Nigeria | North Korea | Norway | Oman | Peru | Philippines | Poland | Portugal | Qatar | Romania| Russia | Saudi Arabia | Senegal | Serbia |Seychelles | Singapore | Slovakia | Slovenia | South Africa | Georgia | Korea | Spain | Sri Lanka | Suriname | Sweden |Switzerland | Taiwan | Tajikistan | Tanzania | Thailand | Togo | Tunisia |Turkey | Turkmenistan| Uganda | Ukraine | UAE | NZ | United States | United Arab Emirates | Venezuela | Vietnam | Yemen | Zimbabwe | London | Birmingham | Bristol | Manchester | Southampton | Liverpool | Austin | Miami | Houston | Hobart |
Hamburg | Milan | Lisbon | Warsaw | Tehran | Paris | Berlin | Rome | Vienna | Barcelona | Prague | Budapest | Madrid | Munich | Kyiv | Oslo | Helsinki | Zurich | Bucharest | Saint Petersburg | Lagos | SOFLA | Athens | Copenhagen | Amsterdam | Stockholm | Istanbul | Toronto | Bangkok | Ho chin minh | Ottawa | Rio de janerio | Bogota | Sao Paulo | Santiago | Lima | Quito | Caracas | Salvador | Belo Horizonte | Moscow | Nairobi | Cairo | Luanda | Addis Ababa | Kinshasa | Mogadishu | Algiers | Maputo | Abuja | Kampala | Cape Town | Durban | Johannesburg | Antananarivo | Harare | Lusaka | Chicago | Philadelphia | Port – au – Prince | Havana |Vancouver | Washington D.C | Guatemala | Dallas | Phoenix | San Diego | Tokyo | Beijing | Shanghai | Bangkok | Taipei | Seoul | Kuala Lumpur | Hong Kong | Hanoi | Ho Chi Minh | Manila | Jakarta | Osaka | Dhaka | Chiang Mai | Chongqing | Phnom Pehn | Guangzhou | Tianjin | Baghdad | Riyadh | Tehran | Chengdu | Nanjing | Shenzhen | Zhengzhou | Hangzhou | Wuhan | Istanbul | Thimpu | Pyongyang | Nagoya | Quanzhou | Ulaanbaatar | Xi An | Wenzhou | Baku | Yerevan | Tbilisi | Dubai | Abu Dhabi | Sharjah | Ajman | Jeddah | Riyadh | Dammam| Doha | Muscat | Jerusalem | Manila | Male | Kabul | Colombo | Damascus | Kathmandu | Manama | Ashgabat | Bandar Seri Begawan | Dushanbe | Laos | Colombo | Tashkent | Sana’a | Naypyidaw | Sydney | Melbourne | Kolkata | Brisbane | Canberra | Perth | Gold Coast | Adelaide | Hobart | Auckland | Wellington | Christchurch |
Alabama | Alaska | Arizona | Arkansas | California | Colorado | Florida | Georgia | Hawaii | Idaho | illinois | Indiana | Kansas | Louisiana | Maine | Maryland | Massachusetts |'Michigan | Minnesota | Mississippi | Missouri | Montana | Nebraska | Nevada | New Hampshire | New Jersey | New Mexico | New York | North Carolina | Carolina | Ohio |
Oklahoma | Pennsylvania | Texas | Virginia | Washington | Wyoming | Utah | Vermont | Alabama | Los Angeles | Chicago | Houston | Phoenix | Philadelphia | San Antonio |
San Diego | Dallas | Austin | San Jose | Columbus | Charlotte | Indianapolis | San Francisco | Seattle | El Paso | Boston | Portland | Lousville | Detroit | Baltimore | Atlanta |
Miami | Oakland | Orlando | Saint Paul | ST Pittsburgh | Lincoln | ST Louis | Ontario | Hayward | Roseville | Columbia |
